2011 Square D HVL/cc 15kV Metal-Enclosed Load Interrupter Switchgear – 600A, 40kA

Square D HVL/cc 15kV Metal-Enclosed Load Interrupter Switchgear – 600A, 40kA

Per Drawings and the Bill of Materials (available on request) these are configured as 6 feeder breaker/switch sections plus 1 incoming section—essentially a 6-breaker lineup.

The front elevation drawing shows:

• FEEDER Sections 1–6
• INCOMING Section 7

The Bill of Materials lists:

• 6 HVL/cc grounded load-break switches
• 6 motor operator assemblies
• 6 voltage indicators
• Six separate key interlock sets

Applications:

• Utility distribution
• Industrial plants
• Large commercial facilities
• Substation feeder switching
• Transformer primary protection

Click REQUEST QUOTE anywhere you see it on our site to receive a quote, with Pricing and Specs, directly to your email!!

* All Descriptions, Specifications and Features are correct to the best of our knowledge. Interested buyers should verify before purchasing.
